Key Characteristics:

1. It exhibits an unbalanced configuration.
2. The system is affixed to the shaft using Allen screws.
3. Its functionality remains unaffected by the direction of rotation.

Operating Limits:

• It accommodates inner diameters (d1) ranging from 15.8 to 100 mm.
• It can withstand pressures (p) of up to 10 kg/cm².
• It is suitable for linear velocities (v) up to 15 m/s.
• The temperature range (t) it operates within spans from -15°C to +200°C (). ( Please note that the temperature resistance depends on the material used for the secondary seals.)

Product Description:

Designed for both internal and external mounting, this mechanical seal boasts a compact size that makes it an ideal choice for lobe pumps. Even when handling fluids laden with particles or sticky, viscous substances, the wave spring within the seal remains unobstructed and free-flowing. Furthermore, the use of stainless steel for the rotating part of the mechanical seal, which is the most common combination, imparts robustness and resistance, ensuring its durability and effectiveness.
