Wave Spring Seal AWS10

PDF PDF

CHARACTERISTICS:

• Unbalanced.
• Single conical spring.
• Dependent on the rotation direction
• Exchangeable Contact Surfaces.

OPERATING LIMITS -

d1= 10 to 100 mm
p= 10 kg/cm²
v= 20 m/s
t= -20 to +200ºC (*)

(*) The temperature resistance depends on the material of the secondary seals used.
The operating limits are defined by the PV factor which is determined for the sealing system characteristics and those of the application.

Description

Recommended for working with sticky fluids and fluids laden with particles and fibres. Unlike the multispring models, the wave spring model cannot be blocked or obstructed and its open leaf designproduces a self-cleaning effect. Standard L9 type stationary part. Seal compliant with standard EN 12756 (KU).
Available with a pumping ring on the casing to reduce the temperature between the contact surfaces and facilitate the barrier fluid movement in the case of double mounting (AWS10-F).
