Multi Spring Seals AMS11

PDF PDF

CHARACTERISTICS:

• Equilibrado
• Sistema Rotacion Independiente
• Multimuelle
• External Mounting

OPERATING LIMITS -

d1= 18 to 100 mm
p= 10 kg/cm²
v= 20 m/s
t= -15 to +200ºC (*)

(*) The temperature resistance depends on the material of the secondary seals used.
The operating limits are defined by the PV factor which is determined for the sealing system characteristics and those of the application.

Description

The contact surface of the rotating part can be detached, which makes this model extremely versatile as it is easy to exchange contact surfaces made of different materials. Seal compliant with standard EN 12756.
