Multi Spring Seals AMS20 / AMS20T

PDF PDF

CHARACTERISTICS:

• Unbalanced.
• System attached to the shaft by allen screws.
• Not dependent on the rotation direction.

OPERATING LIMITS -

d1= 14 to 100 mm
p= 10 kg/cm²
v= 20 m/s
t= -15 to +200ºC (*)

(*) The temperature resistance depends on the material of the secondary seals used. The operating limits are defined by the PV factor which is
determined for the sealing system characteristics and those of the application.

Description

The set of springs placed around the contact surface of the rotating part generates a more uniformed load than in models with a single spring. The AMS20 is suitable for many different applications. Seal compliant with standard EN 12756 (KU). The AMS20T uses a PTFE wedge as a secondary seal and is appropriate for highly aggressive chemicals and for thermal oils with high temperatures. The version in inches has a standard stationary PF. L22 part.
