Bellows Seals - AR / ARB31

PDF PDF

CHARACTERISTICS:

• Unbalanced.
• Not dependent on the rotation direction
• Single cylindrical spring.

OPERATING LIMITS -

d1= 6 to 70 mm
p= 6 kg/cm²
v= 10 m/s
t= -20 to +140ºC (*)
(*) The temperature resistance depends on the material of the
secondary seals used. The operating limits are defined by the PV factor which is determined for the sealing system characteristics and those of the application.

Description

Economic mechanical seal with small dimensions, used in large household pump productions for recirculating water or for working conditions with low demands.
