Bellows Seals - AMB86

PDF PDF

CHARACTERISTICS:

• Balanced.
• Graphite wedge
• Not dependent on the rotation direction.

OPERATING LIMITS -

d1= 25 to 100 mm
p= 20 kg/cm²
v= 25 m/s
t= -75 to +425ºC (*)

(*) The temperature resistance depends on the material of the secondary seals used. The operating limits are defined by the PV factor which is determined for the sealing system characteristics and those of the application.

Description

Internally balanced, with no need for a stepped shaft (models AWS10B, AMS20B). The graphite wedge allwos applications at very high temperatures. Appropriate for applications with sticky or high viscosity fluids as its open leaf design generates a selfcleaning effect. In addition it is suitable for application at moderate pressures as well as with very aggressive fluids, both chemically and mechanically terms. Very often used in compressors
