Axial Spring Seal - Conical AS60 / AS60DIN

PDF PDF

CHARACTERISTICS:

• Balanced.
• System attached to the shaft by allen screws.
• Not dependent on the rotation direction.

OPERATING LIMITS:
d1= 10 to 140 mm
p= 10 kg/cm²
v= 20 m/s
t= -20 to +200ºC (*)

(*) The temperature resistance depends on the material of the secondary seals used.
The operating limits are defined by the PV factor which is determined for the sealing system characteristics and those of the application.

Description

A versatile, robust single seal that is widely used in many different industrial and household applications. The rotating part, with a compact design, only permits the use of secondary seals made of elastic materials. If it should be necessary to use secondary seals made of PTFE for reasons related to temperature, the AS61 model is recommended.
Types: AS61 and AS61 DIN: Secondary seals made of PTFE and contact surfaces in GB. AS60DIN: standardised models in accordance with EN 12756 NU.
