Single Cartridge Seals - ASC40

PDF PDF

CHARACTERISTICS:

• Balanced.
• Multispring.
• Not dependent on the rotation direction.
• Flushing connections.

OPERATING LIMITS:

d_{1} = 25, 4 to 95,3 mm
p = 25kg / c * m ^ 2
v = 16m / s
t= - 15to +200^ C(^ ^ )

(*) The temperature resistance depends on the ma- terial of the secondary seals used. The operating limits are defined by the PV factor which is determined for the sealing system charac- teristics and those of the application.

Description

A single cartridge with connections for flushing the seal contact faces. The springs are protected from the product to prevent blocking in applications with parti- cle-laden fluids. The standard flange has a connection for flushing to clean and cool the faces. Recomended for flange pumps ANSI Standard bore and ansi big bore
