Double Agitator Seal - ADC80

PDF PDF

CHARACTERISTICS:

• Balanced.
• Multispring.
• Not dependent on the rotation direction.
• Flushing connections.

OPERATING LIMITS:

d_{1} = 25, 4 to 95,3 mm
p = 25kg / c * m ^ 2
v = 16m / s
t= - 15to +200^ C(^ ^ )

(*) The temperature resistance depends on the ma- terial of the secondary seals used. The operating limits are defined by the PV factor which is determined for the sealing system charac- teristics and those of the application.

Description

DESCRIPTION: A double cartridge with a "face to face" arrangement which permits operation with barrier fluid in excessive pressure with respect to the working fluid (P1+1.5-2 Kg/cm³) The sleeve includes a pumping ring that facilite the barrier fluid movement. The connections of Liquid barreir IN and OUT have to be connected according the rotation direction.
