Multi Spring Seals AMS15D

PDF PDF

CHARACTERISTICS:

• Unbalanced.
• System attached to the shaft by allen screws.
• Not dependent on the rotation direction

OPERATING LIMITS -

d1= 20 to 100 mm
p= 12 kg/cm²
v= 20 m/s
t= -40 to +200ºC (*)

(*) The temperature resistance depends on the material of the secondary seals used. The operating limits are defined by the PV factor which is determined for the sealing system characteristics and those of the application.

Description

Double seal for working with barrier fluids in which the springs are isolated from the fluid product. API 53A and AP I54 assemblies. Recommended in applications with toxic, pollutant or potentially dangerous products in which safety is an important factor.
