Multi Spring Seals AMS14

PDF PDF

CHARACTERISTICS:

• Balanced.
• System attached to the shaft by allen screws.
• Not dependent on the rotation direction.

OPERATING LIMITS -

d1 = 18 to 100 mm
p= 14 kg/cm²
v= 15 m/s
t= -15 to +200ºC (*)

(*) The temperature resistance depends on the material of the secondary seals used. The operating limits are defined by the PV factor which is determined for the sealing system characteristics and those of the application

Description

Suitable for working in applications with high pres The springs are not in contact with the fluid. Ideal for working with particle-laden fluids in which standard designs tend to become blocked. Internally balanced, with no need for a stepped shaft sures. The O-ring resting on the shaft does not cause wear as there is no axial movement (changes in pressure).
